TypeSpec: API Design Before Code

Most teams design APIs one of two ways: write code first and extract OpenAPI from annotations, or write OpenAPI YAML directly and generate types from it. Both have the same problem — you end up maintaining two things (schema + code) that need to stay in sync.

Photo by DFY® 디에프와이 on Unsplash

TypeSpec is Microsoft's answer: a dedicated language for expressing API shapes, from which you generate OpenAPI, JSON Schema, Protobuf, client SDKs, and server scaffolding. One source of truth, multiple outputs.

Why a Dedicated API Language

OpenAPI YAML gets verbose fast. A simple CRUD endpoint with proper schemas, error responses, and pagination can run to hundreds of lines. Maintaining it by hand is error-prone; generating it from code annotations couples your API contract to your implementation choices.

TypeSpec treats API design as a first-class programming task:

import "@typespec/http";
using TypeSpec.Http;

model User {
  id: string;
  email: string;
  name: string;
  createdAt: utcDateTime;
}

@route("/users")
interface Users {
  @get list(): User[];
  @post create(@body user: OmitProperties<User, "id" | "createdAt">): User;
  @get read(@path id: string): User | NotFoundResponse;
  @patch update(@path id: string, @body patch: UpdateableProperties<User>): User;
  @delete remove(@path id: string): void;
}

This generates a complete OpenAPI 3.0 spec, including proper response schemas and HTTP status codes.

Installation

npm install -g @typespec/compiler

# Initialize a new TypeSpec project
mkdir my-api && cd my-api
tsp init --template rest

# Or add to existing project
npm install --save-dev @typespec/compiler @typespec/http @typespec/rest @typespec/openapi3

Project structure:

my-api/
├── main.tsp         # Main TypeSpec file
├── tspconfig.yaml   # Compiler configuration
└── package.json

Basic TypeSpec Syntax

Models (Schemas)

// Simple model
model Product {
  id: string;
  name: string;
  price: float64;
  category: string;
  inStock: boolean;
}

// Extend a model
model DigitalProduct extends Product {
  downloadUrl: string;
  fileSize: int64;
}

// Template models
model Page<T> {
  items: T[];
  total: int64;
  page: int32;
  pageSize: int32;
}

// Utility types
model CreateProductRequest is OmitProperties<Product, "id">;
model UpdateProductRequest is UpdateableProperties<Product>;

Enums and Unions

enum OrderStatus {
  Pending: "pending",
  Processing: "processing",
  Shipped: "shipped",
  Delivered: "delivered",
  Cancelled: "cancelled",
}

// Union types
alias StringOrNumber = string | int32;
alias Response<T> = T | NotFoundResponse | UnauthorizedResponse;

Decorators

TypeSpec uses decorators to add HTTP semantics, validation, and documentation:

model User {
  @format("email")
  email: string;

  @minLength(8)
  @maxLength(72)
  password: string;

  @minValue(0)
  @maxValue(120)
  age?: int32;

  @doc("ISO 3166-1 alpha-2 country code")
  country?: string;
}

HTTP Operations

import "@typespec/http";
using TypeSpec.Http;

@service({
  title: "Product API",
  version: "1.0.0",
})
@server("https://api.example.com", "Production")
namespace ProductAPI;

@route("/products")
@tag("Products")
interface ProductOperations {
  @doc("List all products with optional filtering")
  @get
  list(
    @query category?: string,
    @query page?: int32 = 1,
    @query pageSize?: int32 = 20,
  ): Page<Product>;

  @doc("Create a new product")
  @post
  create(@body product: CreateProductRequest): {
    @statusCode statusCode: 201;
    @body product: Product;
  };

  @doc("Get a specific product")
  @get
  read(@path id: string): Product | NotFoundResponse;
}

Authentication

import "@typespec/http";
using TypeSpec.Http;

// Define security scheme
@useAuth(BearerAuth)
namespace SecureAPI;

// Or per-operation
@useAuth(BearerAuth | ApiKeyAuth<ApiKeyLocation.header, "X-API-Key">)
interface AdminOperations {
  @get
  dashboard(): DashboardData;
}

Generating Output

# Compile to OpenAPI 3.0
tsp compile main.tsp

# Output goes to tsp-output/ by default
ls tsp-output/@typespec/openapi3/
# openapi.yaml

Configure output in tspconfig.yaml:

emit:
  - "@typespec/openapi3"
  - "@typespec/json-schema"

options:
  "@typespec/openapi3":
    output-file: "openapi.yaml"
    openapi-versions:
      - "3.0.0"
  "@typespec/json-schema":
    output-dir: "json-schemas"

Generating Clients

With the generated OpenAPI spec, use any OpenAPI client generator:

# TypeScript client with openapi-typescript
npx openapi-typescript tsp-output/@typespec/openapi3/openapi.yaml -o src/api.ts

# Python client
openapi-generator-cli generate \
  -i tsp-output/@typespec/openapi3/openapi.yaml \
  -g python \
  -o clients/python

# Go client
openapi-generator-cli generate \
  -i tsp-output/@typespec/openapi3/openapi.yaml \
  -g go \
  -o clients/go

CI Integration

Check that generated specs don't drift from the source:

# .github/workflows/api-check.yml
name: API Spec Check
on: [push, pull_request]

jobs:
  check-spec:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4
      - uses: actions/setup-node@v4
        with:
          node-version: 20

      - run: npm ci
      - run: npx tsp compile main.tsp

      - name: Check for spec drift
        run: |
          if ! git diff --quiet tsp-output/; then
            echo "Generated spec has changed. Run 'tsp compile' and commit."
            git diff tsp-output/
            exit 1
          fi

TypeSpec vs. Alternatives

TypeSpec fills the gap between "write OpenAPI YAML" (verbose, no reuse) and "code-first with annotations" (couples spec to implementation). It's most valuable for teams with multiple consumers of an API, or where the contract needs to exist independently of any implementation.
